Flexible Elbow – Hidden Gutter System (SRU)

The flexible elbow carries rainwater from the foot of the downpipe into the inspection pit below. Because it bends rather than holding a fixed angle, it copes with whatever offset the site presents – the pit rarely sits perfectly beneath the pipe, and the elbow simply takes up the difference instead of forcing a run of rigid bends and cut sections to bridge the gap.

That flexibility also makes the connection forgiving during installation. Ground levels shift, pit positions get set before the façade is finished, and small discrepancies at the base of a concealed downpipe would otherwise mean reworking the joint. Here the elbow is directed to whatever angle the connection needs. It steps from a 90 mm downpipe to a 110 mm outlet, matching the standard drainage size at the pit.

Key features

• Drains rainwater from the downpipe straight into the inspection pit
• Flexible body – set the pipe to any angle the connection requires
• Absorbs misalignment between downpipe and pit without extra fittings
• Steps from Ø 90 mm to Ø 110 mm
• Simplifies the below-ground connection on concealed downpipe runs
• Part of the SRU hidden gutter range

Dimensions

Check the downpipe and pit inlet diameters before ordering to confirm the 90/110 mm step suits your drainage arrangement.
