Rolled Steel Angles – Unequal
Rolled Steel Angles (RSA-U)
Engineered for strength and precision, our RHS steel offers unmatched versatility to meet the demands of any construction project.
Hot Rolled Steel Angles (RSA-U)
They are described by giving both leg lengths (longer first) and the wall thickness (all in mm), eg. 150 x 100 x 8 RSA. With the longer leg being in a vertical position, its loading capabilities are greater than equal angles, therefore they are often used as lintels.
Unequal angles are also used as brackets for cleat connections. Similar to equal angles, they are often used for balconies, platforms, stairs, concrete supports, etc.
Examples of RSA-U products in our range
It’s simple – buy online, use the calculator or get in touch with our advisers.
Common applications for Hot Rolled Steel Angles (Unequal)
Construction and Structural Framing
Infrastructure Projects
Industrial Equipment and Machinery
Architectural and Miscellaneous Fabrication
RSA-U Dimensions (Size & Weight Chart)
| No. | Type | Weight [kg/m] |
Height [mm] |
Width [mm] |
Thickness [mm] |
|---|---|---|---|---|---|
| 01 | 30 x 20 x 3 RSA | 1.1 | 30 | 20 | 3 |
| 02 | 30 x 20 x 4 RSA | 1.5 | 30 | 20 | 4 |
| 03 | 40 x 20 x 4 RSA | 1.8 | 40 | 20 | 4 |
| 04 | 40 x 25 x 4 RSA | 1.9 | 40 | 25 | 4 |
| 05 | 45 x 30 x 4 RSA | 2.3 | 45 | 30 | 4 |
| 06 | 50 x 30 x 5 RSA | 3.0 | 50 | 30 | 5 |
| 07 | 60 x 30 x 5 RSA | 3.4 | 60 | 30 | 5 |
| 08 | 60 x 40 x 5 RSA | 3.8 | 60 | 40 | 5 |
| 09 | 60 x 40 x 6 RSA | 4.5 | 60 | 40 | 6 |
| 10 | 65 x 50 x 5 RSA | 4.4 | 65 | 50 | 5 |
| 11 | 70 x 50 x 6 RSA | 5.4 | 75 | 50 | 6 |
| 12 | 75 x 50 x 6 RSA | 5.7 | 75 | 50 | 6 |
| 13 | 75 x 50 x 8 RSA | 7.4 | 75 | 50 | 8 |
| 14 | 80 x 40 x 6 RSA | 5.4 | 80 | 40 | 6 |
| 15 | 80 x 40 x 8 RSA | 7.1 | 80 | 40 | 8 |
| 16 | 80 x 60 x 7 RSA | 7.4 | 80 | 60 | 7 |
| 17 | 100 x 50 x 6 RSA | 6.8 | 100 | 50 | 6 |
| 18 | 100 x 50 x 8 RSA | 9.0 | 100 | 50 | 8 |
| 19 | 100 x 65 x 7 RSA | 8.8 | 100 | 65 | 7 |
| 20 | 100 x 65 x 8 RSA | 9.9 | 100 | 65 | 8 |
| 21 | 100 x 65 x 10 RSA | 12.3 | 100 | 65 | 10 |
| 22 | 100 x 75 x 8 RSA | 10.6 | 100 | 75 | 8 |
| 23 | 100 x 75 x 10 RSA | 13.0 | 100 | 75 | 10 |
| 24 | 100 x 75 x 12 RSA | 15.4 | 100 | 75 | 12 |
| 25 | 120 x 80 x 8 RSA | 12.2 | 120 | 80 | 8 |
| 26 | 120 x 80 x 10 RSA | 15.0 | 120 | 80 | 10 |
| 27 | 120 x 80 x12 RSA | 17.8 | 120 | 80 | 12 |
| 28 | 125 x 75 x 8 RSA | 12.2 | 125 | 75 | 8 |
| 29 | 125 x 75 x 10 RSA | 15.0 | 125 | 75 | 10 |
| 30 | 125 x 75 x 12 RSA | 17.8 | 125 | 75 | 12 |
| 31 | 135 x 65 x 8 RSA | 12.2 | 135 | 65 | 8 |
| 32 | 135 x 65 x 10 RSA | 15.0 | 135 | 65 | 10 |
| 33 | 150 x 75 x 9 RSA | 15.4 | 150 | 75 | 9 |
| 34 | 150 x 75 x 10 RSA | 17.0 | 150 | 75 | 10 |
| 35 | 150 x 75 x 12 RSA | 20.2 | 150 | 75 | 12 |
| 36 | 150 x 75 x 15 RSA | 24.8 | 150 | 75 | 15 |
| 37 | 150 x 90 x 10 RSA | 18.2 | 150 | 90 | 10 |
| 38 | 150 x 90 x 12 RSA | 21.6 | 150 | 90 | 12 |
| 39 | 150 x 90 x 15 RSA | 26.6 | 150 | 90 | 15 |
| 40 | 150 x 100 x 10 RSA | 19.0 | 150 | 100 | 10 |
| 41 | 150 x 100 x 12 RSA | 22.5 | 150 | 100 | 12 |
| 42 | 200 x 100 x 10 RSA | 23.0 | 200 | 100 | 10 |
| 43 | 200 x 100 x 12 RSA | 27.3 | 200 | 100 | 12 |
| 44 | 200 x 100 x 15 RSA | 33.7 | 200 | 100 | 15 |
| 45 | 200 x 150 x 12 RSA | 32.0 | 200 | 150 | 12 |
